Crawler sewage treatment machine

【Crawler sewage treatment machine】

Application and introduction

Sbdy series belt filter is a new type of mechanical dehydration equipment developed by our company after introducing foreign advanced technology and digesting the new belt roller dehydration principle and advanced design at home and abroad. It has the characteristics of continuous production, large processing capacity, high dehydration efficiency, low moisture content of filter cake, stable performance, high degree of automation, convenient operation and so on.

Scope of application

The machine can be widely used in various tailings sludge treatment, urban domestic sewage, textile printing and dyeing, electroplating, papermaking, leather, starch, protein powder, brewing, food processing, coal washing, petrochemical industry, chemical fiber and ceramics. It is also suitable for solid-liquid separation and liquid leaching process of industrial production.

Design performance advantages

1. Automatic tightening of filter belt and automatic deviation correction;

2. Low energy consumption and long service life;

3. Easy to manage and maintain;

4. High dehydration rate and high solid content of filter cake;

5. Low noise and low dosage of chemicals;

6. Spray head and washing mechanism are used for automatic cleaning.

Mechanical manufacturing advantages

1. The main frame is welded with thick square pipe, and the bearing seat has the characteristics of firmness, anti-corrosion and waterproof.

2. The system operation cost and maintenance cost are significantly lower than those of similar products.

3. Continuous operation, large treatment capacity and low moisture content of filter cake.

Filtration and dehydration process

1. Gravity concentration and dehydration area

The sludge is evenly sent to the filter belt through the sludge distributor, and moves forward with the filter belt. The free water is stripped out under the action of self weight, concentrated and ready for preloading.

2. Wedge preloading dehydration area

The sludge enters the pressure dehydration area from the gravity dehydration area and loses its fluidity. Through the wedge-shaped area, the pressure and concentration gradually increase and prepare for high-pressure dehydration.

3. High pressure dehydration of extrusion roll

In the high-pressure zone, the capillary in the sludge is squeezed out in combination with water pressure, the volume shrinks, and the free water and bound water are extruded to form a filter cake.
